Impulse Heat Sealing Sealer Manual Packaging Machine PFS-150
Make and Sale Impulse Heat Sealing Sealer PFS-150 Manual 150mm / 15cm / 6 inches Wide Plastic Bag Heat Packaging Machine From Zhejiang Tianyu Industry Co., Ltd. Supplier Factory Manufacturer in China.Impulse Heat Sealing Sealer Plastic Body PFS-Series Manual Plastic Bag Heat Packaging Machine Can Seals polypropylene and polyethylene bags and tubing up to 6 mil thick - no warm-up required. Flat element sealer does not melt through bags and tubing,use scissors or other cutting instrument to trim bag tops and tails. Creates super strong, tamper-evident tail flap.
脉冲热封封口机Plastic Body PFS-Series Manual Plastic Bag Heat Packaging Machine is ideal to protect products against atmospheric contaminations and moisture.They are made from food grade plastic material and are developed especially for machines that perform an external vacuum.The Vacuum pouches comprise of 2 smooth layers of polyamide(nylon)-polyethylene barrier material. 3mil is the most common thickness for vacuum pouches that meets USDA standards for food packaging. These pouches would not have a layer of fine mesh because the chamber vacuum machines evacuate air after the pouch is within the chamber.Under Packman Packaging’s food & pharmaceutical packaging’s offerings, customers can avail high quality vacuum pouches, specially designed to extend the shelf life of frozen meat, fish, poultry, cheese and medicines.
Max. Sealing Length:150mm / 15cm / 6 inches
Sealing Width: 2mm
Heat Time: 0.2 -1.5s
Can Make OEM Products
Model: PFS-150
Color:Gray,Black,Blue,White
Max.Sealing Length: 150mm / 15cm / 6 inches
Sealing Width: 2mm
Sealing Thickness: PE 0.06-0.2mm / PP 0.03-0.8mm
Heating Time:0.2-1.5S
Source: AC110V / 50Hz or AC220V/60Hz
Power: 220W
Dimensions: 295X95X180mm (L X W X H)
Weight: 1.24 Kg
Suitable for: PE/PP Bags
Plug Type: US Standard
脉冲热封封口机Plastic Body PFS-Series Manual Plastic Bag Heat Packaging Machine is not continuously heated; heat is only generated only when the jaw is closed and current flows. When the bag is placed in the impulse heat sealer, the jaw is closed and pressure maintained for the time of the seal (while the light is on). Then pressure is held for about 2 seconds to allow the seal to cool. This means that ther is no heat up time and no power is consumed when the impulse heat sealer is not in use.
脉冲热封封口机PFS-150 Manual 150mm / 15cm / 6 inches Wide Plastic Bag Heat Packaging Machine Package Includes:
1 X PFS-150 Impulse Heat Sealing Sealer
2 X 150mm Long Extra Heating Wires
2 X 150mm Long Extra High Temperature Clothes
1 X English User Manual
PFS-150 Impulse Heat Sealing Sealer Weight: 1.24 Kg
1 PCS/Color Box
Color Box Size:29.5X9.5X18cm
20 PCS/CTN
Carton Size:52.5X29.5X65.5cm
G.W/CTN:25.84 Kg
HS CODE:8422303090
脉冲热封封口机Plastic Body PFS-Series Manual Plastic Bag Heat Packaging Machine Specification:
| Model | PFS-100 | PFS-150 | PFS-200 | PFS-250 | PFS-300 | PFS-400 |
| Impulsevoltage | AC220V/50HZ or AC110V/60HZ | |||||
| 脉冲功率 | 150W | 220W | 300W | 350W | 400W | 600W |
| Max. sealing length | 100mm/4 inches/10cm | 150mm/15cm/6 inches | 200mm/8 inches/20cm | 250mm/10 inches/25cm | 300mm/12 inches/30cm | 400毫米/ 16英寸/ 40厘米 |
| Sealing width | 2mm | 2mm | 2mm | 2mm | 2mm | 3mm |
| Max sealing thickness | 0.6mm | 0.6mm | 0.6mm | 0.8mm | 0.8mm | 0.8mm |
| Adjustable heating time | 0.2-1.5 S | 0.2-1.5 S | 0.2-1.5 S | 0.2-1.5 S | 0.2-1.5 S | 0.2-2 S |
| Dimensions (LX W XH)mm | 245X95X170 | 295X95X180 | 330X100X172 | 380X102X183 | 430X102X175 | 575X105X190 |
| Weight | 1.06KGS | 1.24公斤 | 1.26KGS | 1.58KGS | 1.68KGS | 2.82KGS |
| Package | 1 PCS/Color Box | |||||
| QTY/CTN | 20 PCS | 20 PCS | 10 PCS | 10 PCS | 10 PCS | 10 PCS |
| Carton Size(mm) | 490X255X640 | 525X295X655 | 510X345X360 | 535X395X360 | 525X445X360 | 590X555X390 |
| G.W/CTN(Kg) | 23 | 25.84 | 13.38 | 16.4 | 17.78 | 26.5 |
| QTY(sets)/20'GP | 7000 | 5500 | 4450 | 3700 | 3350 | 2200 |
| QTY(sets)/40'GP | 14500 | 11500 | 9200 | 7650 | 6900 | 4550 |
| QTY(sets)/40'HQ | 17000 | 13400 | 10800 | 8950 | 8100 | 5350 |
